Channel Magnet Assemblies
Overview
Adams Magnetic Products offers high-performance channel magnet assemblies, designed to provide exceptional holding strength on one large surface. These magnets are ideal for various industrial and consumer applications.
What are Channel Magnet Assemblies?
Channel magnets consist of a strong ceramic or rubber magnet set into a plated steel channel, equipped with holes, loops, or threaded nuts for versatile mounting options.
Advantages
- Enhanced Holding Strength: Up to 32 times stronger than individual ceramic magnets.
- Versatile Mounting: Multiple mounting options with holes, loops, or threaded nuts.
- Customizable: Available in various colors and packaging options to meet specific requirements.
Features
- Material Options: Made with ceramic or rubber magnets.
- Durability: Plated steel channel enhances durability and corrosion resistance.
- Flexible Applications: Customizable dimensions and configurations available.
Applications
Channel magnet assemblies are ideal for:
- Door latches
- Vehicle license plate holders
- Sign and banner holders
- Blueprint holders
Specifications
Adams supplies the following channel magnet assemblies from stock, with dimensions listed in inches. We can also make custom channel magnet assemblies to meet your exact specifications.
Contact us at 800-747-7543 if you don’t see what you’re looking for in this brief listing.
Low Profile Neo Channels
| Width | Height | Length | Pull lbs | Mounting | Finish | Magnet Item # | Matching Rubber Boot |
|---|---|---|---|---|---|---|---|
| 0.750 | 0.188 | 2.000 | 80 | 2 Ctr holes for #8 Flathead | Clear Zinc | 65CN0007 | 69R0003 |
| 1.250 | 0.188 | 2.000 | 92 | 2 Ctr holes for #8 Flathead | Clear Zinc | 65CN0008 | 69R0002 |
Rubber Coated Neodymium Magnet Assemblies
Great sheer strength compared to non-rubber-coated channel magnets
| Item# | Width | Height | Length | Mounting | Pull lbs |
|---|---|---|---|---|---|
| 65R0017 | 34 mm | 17 mm | 95 mm | M6 X 1 threaded hole | 157 |
| 65R0027 | 61 mm | 27.5 mm | 202 mm | M10 1.5 stud | 670 |
| 65R0021 | 60 mm | 21 mm | 175 mm | 2 M6X15 threaded holes with bolts | 750 |
Standard Channel Magnets
| Stock# | Width | Height | Length | Mounting | Pull lbs | Finish | Item# | View Print |
|---|---|---|---|---|---|---|---|---|
| CH-10-R | 0.890 | 0.25 | 1 | 0.130 center hole | 5 | Nickel | 65CA0001 |  |
| CH-10-C | 0.875 | 0.25 | 1 | 0.125 center hole | 10 | Nickel | 65CA0006 | |
| CH-10 | 0.88 | 0.25 | 1 | 0.125 center hole | 30 | Zinc | 61ANZ002 | |
| CH-10-2 | 0.95 | 0.320 | 2 | none | 14 | Nickel | 65CB0005 | |
| CH-10-2 | 0.945 | 0.315 | 2 | loop | 14 | Nickel | 65CB0003 | |
| CH-10-2 | 0.960 | 0.315 | 2.63 | 0.170 side holes | 14 | Nickel | 65CB0002 | |
| CH-32 | 1.050 | 0.465 | 2.7 | 0.192 side holes | 25 | Zinc | 65CJ0001 | |
| CH-32 | 1.040 | 0.462 | 2.7 | loop | 25 | Zinc | 65CJ0002 | |
| CH-3 | 0.900 | 0.255 | 3 | welded nut | 22 | Nickel | 65CI0016 | |
| CH-35 | 1.5 | 0.455 | 3 | 0.262 slots | 60 | Zinc | 65CK0001 | |
| CH-6 | 1.52 | 0.441 | 6 | 0.250 side holes | 100 | Zinc | 65CM0001 | |
| CH-8 | 1.065 | 0.470 | 8 | 0.435 slots | 60 | Zinc | 65CN0001 | |
| CH-8 | 1.075 | 0.500 | 7.9 | 0.430 slots | 30 | Black | 61N0002 | |
| CH-12 | 0.710 | 0.200 | 12 | 0.150 side holes | 10 | Zinc | 65CC0001 | |
| CH-12-3 | 1.72 | 0.62 | 12 | 0.250 side holes | 150 | Zinc | 65CD0001 | |
Contact Us
Adams is ready to be a part of your products with off-the-shelf and custom applications. Contact us to find out more.
